Description
The multiple award winning range of Ultra Quiet AA chassis Ecodan monobloc air source heat pumps are
designed specifically to suit the demands of the UK market. These units can be cascaded with up to 6 other identical units to provide up to 84kW of heat output.
The innovative, stylish and compact single fan outdoor unit utilises advanced technologies to deliver improved efficiencies. Designed
for a wide range of applications, the market leading low noise levels virtually eliminate the need for planning permission, maximises
installation options and is a viable solution for all types of domestic requirements that the UK housing market demands.
The Ecodan comes with a range of compatible storage tanks in a range of capacities; pre-plumbed or packaged. To select the appropriate tank for your application select it in the drop down options menu.
Key Features: Self-contained unit, only requiring water and electric connections, low maintenance and quiet operation, operates outside as low as -20°C, Optimised low ambient Defrost control and operation down to -7°C, Hybrid function – for use with conventional old fashioned boilers, Energy monitoring as standard, multiple unit cascade function. Supplied with a Wi-Fi interface.
Components
Warranty
Technical Specifications
Nominal capacity 14.0kW
Compressor type Scroll
Refrigerant type R32
Refrigerant volume 3.3kg
Nominal flow rate 40.1L/m
Minimum water volume 20 L
-Electrical- Immersion HeaterYes Yes-
Wi-Fi Interface YesYes Yes
F & R Temp Thermistor- YesYes
Flow Temperature Controller YesYes Yes
DHW Upper and Lower Water Temp thermistor YesYes -
DHW Water Temp Thermistor -Yes Yes
-Mechanical- Plate Heat ExchangerYes Yes-
Coil Heat Exchanger -- -
Primary Pump Yes Yes-
Secondary Pump - Yes-
3 Way Valve Yes Yes-
Scale Trap Yes Yes-
Primary System Pressure GaugeYes Yes-
AAVYes Yes-
Filling LoopYes Yes-
Drain ValveYes Yes-
DHW Drain Valve YesYes -
G3 Compliance Kit* YesYes -
Magnetic Filter YesYes Yes
Insulated Flexible Hose YesYes Yes
Flow Sensor YesYes Yes
Business Solutions Partner
Ecodan Selection Tool Access No Yes Yes
Product Warranty (<20kW) 3 Years 5 Years*1*27 Years*1 Free Trainings (per year) 0 0*35*3
